24mm ERM Vibration Motor – 30mm Model TSL-RK370-CODR
If you request a quotation for mass production quantities, contact us for customizations and integration.
TSL-RK-370 Stable Double Copper Heads Vibrator Parameters
The double copper heads vibrator TSL-RK370-CODR is a 24mm ERM vibration motor with a 30mm type design, distinguished by its stable double copper heads vibrator for superior durability and balanced performance. Featuring dual eccentric copper mass heads, this motor ensures consistent vibration output and enhanced heat dissipation, making it ideal for high-duty applications like industrial automation, medical devices, or robotics.
With a double copper heads vibrator diameter of 24.0mm and length of 30.7mm, its compact yet robust design includes 13mm vibrator heads with a thickness of 4.9mm, optimized for precise, multidirectional feedback. The overall motor length of 51mm accommodates the dual-head configuration, ensuring stability in demanding environments. Operating at 6V/12V/24V DC, it delivers adjustable speeds (3,000 RPM at 6V, 6,000 RPM at 12V, 8,500 RPM at 24V), enabling tailored intensity for applications ranging from therapeutic equipment to heavy machinery alerts.
Boasting a power range of 3.69W–8W and low no-load current (420mA–620mA at 12V; 250mA–400mA at 24V), the double copper heads vibrator balances energy efficiency with high torque. Its bidirectional rotation (CW/CCW) offers integration flexibility, while the copper heads resist wear and corrosion, extending lifespan in humid or high-stress conditions. Weighing 61g, it combines ruggedness with precision, making it a standout choice for applications requiring reliable, heavy-duty vibration performance with minimal maintenance.
| Motor Model | TSL-RK370-CODR |
| Eccentric Mass | Double Copper Heads |
| Motor Diameter | 24.0mm |
| Motor Length | 30.7mm |
| Vibrator Head Thickness | 4.9mm |
| Vibrator Head Diameter | 13mm |
| Motor Overall Length | 51mm |
| Rated Voltage | 6V / 12V / 24V DC |
| Rated Speed | 3,000rpm / 6,000rpm / 8,500rpm |
| Power | 3.69W – 8W |
| No Load Current (12V) | 420mA – 620mA |
| No Load Current (24V) | 250mA – 400mA |
| Rotation | CW / CCW |
| Weight | 61g |
Double Copper Heads Vibrator In Industry Outline Drawing
Customized Solutions
Keywords:
tiny vibration motor, 12v dc micro vibration motor, vibrating mini motor,double copper heads vibrator
Development Samples:
Sampling quantities for stocked models are available for ordering directly from us online.
Engineering & Manufacturing:
Please contact one of our Sales Engineers for a quotation for production and consultation for customization and integration services.
Payment Method:
Payment methods : Paypal or T/T
Shipping Method:
1.Delivery: DHL door to door 5-7days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
5.In order to ensure you receive your order tax free upon import, we will declare it with a lower value, pls be noted ,thanks!
FAQ – Frequently Asked Questions
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
Tap:If you request a quotation for mass production quantities, contact us for customizations and integration.We also offer DC motors and Gear motors.
